EduSahara™ Assignment
Name : Polygons
Chapter : Polygons
Grade : ICSE Grade IX
License : Non Commercial Use
Question 1
1.
Identify the figure below
  • (i)
    quadrilateral
  • (ii)
    circle
  • (iii)
    hexagon
  • (iv)
    heptagon
  • (v)
    triangle
Question 2
2.
Identify the figure below
  • (i)
    quadrilateral
  • (ii)
    pentagon
  • (iii)
    heptagon
  • (iv)
    nonagon
  • (v)
    octagon
Question 3
3.
Identify the figure below
  • (i)
    triangle
  • (ii)
    circle
  • (iii)
    octagon
  • (iv)
    heptagon
  • (v)
    hexagon
Question 4
4.
Identify the figure below
  • (i)
    kite
  • (ii)
    trapezium
  • (iii)
    angle
  • (iv)
    parallelogram
  • (v)
    rhombus
Question 5
5.
Identify the figure below
  • (i)
    square
  • (ii)
    rhombus
  • (iii)
    rectangle
  • (iv)
    circle
  • (v)
    parallelogram
Question 6
6.
Identify the figure below
  • (i)
    rectangle
  • (ii)
    trapezium
  • (iii)
    parallelogram
  • (iv)
    triangle
  • (v)
    circle
Question 7
7.
Identify the figure below
  • (i)
    angle
  • (ii)
    kite
  • (iii)
    square
  • (iv)
    parallelogram
  • (v)
    triangle
Question 8
8.
Identify the figure below
  • (i)
    kite
  • (ii)
    rhombus
  • (iii)
    square
  • (iv)
    angle
  • (v)
    circle
Question 9
9.
Identify the figure below
  • (i)
    parallelogram
  • (ii)
    circle
  • (iii)
    kite
  • (iv)
    trapezium
  • (v)
    triangle
Question 10
10.
Identify the figure below
  • (i)
    circle
  • (ii)
    heptagon
  • (iii)
    octagon
  • (iv)
    pentagon
  • (v)
    quadrilateral
Question 11
11.
Identify the figure below
  • (i)
    octagon
  • (ii)
    nonagon
  • (iii)
    hexagon
  • (iv)
    quadrilateral
  • (v)
    pentagon
Question 12
12.
Identify the figure below
  • (i)
    hexagon
  • (ii)
    heptagon
  • (iii)
    triangle
  • (iv)
    nonagon
  • (v)
    pentagon
Question 13
13.
Identify the figure below
  • (i)
    hexagon
  • (ii)
    pentagon
  • (iii)
    triangle
  • (iv)
    circle
  • (v)
    octagon
Question 14
14.
Identify the figure below
  • (i)
    hexagon
  • (ii)
    nonagon
  • (iii)
    triangle
  • (iv)
    angle
  • (v)
    heptagon
Question 15
15.
Identify the figure below
  • (i)
    nonagon
  • (ii)
    hexagon
  • (iii)
    angle
  • (iv)
    decagon
  • (v)
    pentagon
Question 16
16.
In the given two equilateral triangles, find ∠A + ∠C + ∠E + ∠B + ∠D + ∠F .
  • (i)
    362°
  • (ii)
    359°
  • (iii)
    360°
  • (iv)
    361°
  • (v)
    358°
Question 17
17.
The angles of a quadrilateral FGHI are in the ratio 1 : 2 : 3 : 6. Find the measure of each angle of the quadrilateral.
  • (i)
    F
    =
    32°
    ,
    G
    =
    59°
    ,
    H
    =
    88°
    ,
    I
    =
    181°
  • (ii)
    F
    =
    29°
    ,
    G
    =
    58°
    ,
    H
    =
    91°
    ,
    I
    =
    182°
  • (iii)
    F
    =
    28°
    ,
    G
    =
    62°
    ,
    H
    =
    89°
    ,
    I
    =
    181°
  • (iv)
    F
    =
    31°
    ,
    G
    =
    59°
    ,
    H
    =
    92°
    ,
    I
    =
    178°
  • (v)
    F
    =
    30°
    ,
    G
    =
    60°
    ,
    H
    =
    90°
    ,
    I
    =
    180°
Question 18
18.
Two adjacent angles of a parallelogram PQRS are in the ratio 3 : 3. Find the measure of each of its angles.
  • (i)
    P
    =
    91°
    ,
    Q
    =
    89°
    ,
    R
    =
    92°
    ,
    S
    =
    88°
  • (ii)
    P
    =
    90°
    ,
    Q
    =
    90°
    ,
    R
    =
    90°
    ,
    S
    =
    90°
  • (iii)
    P
    =
    92°
    ,
    Q
    =
    89°
    ,
    R
    =
    88°
    ,
    S
    =
    91°
  • (iv)
    P
    =
    88°
    ,
    Q
    =
    92°
    ,
    R
    =
    89°
    ,
    S
    =
    91°
  • (v)
    P
    =
    89°
    ,
    Q
    =
    88°
    ,
    R
    =
    91°
    ,
    S
    =
    92°
Question 19
19.
Three angles of quadrilateral measure 143.73°, 46.26° and 93.14° respectively. Find the measure of the fourth angle
  • (i)
    78.87°
  • (ii)
    74.87°
  • (iii)
    77.87°
  • (iv)
    76.87°
  • (v)
    75.87°
Question 20
20.
Three angles of a quadrilateral are equal and the fourth angle measure 60.61°. What is the measure of each of the equal angles?
  • (i)
    97.80°
  • (ii)
    98.80°
  • (iii)
    99.80°
  • (iv)
    100.80°
  • (v)
    101.80°
Question 21
21.
Which of the following figures is a regular quadrilateral?
  • (i)
    parallelogram
  • (ii)
    trapezium
  • (iii)
    rectangle
  • (iv)
    rhombus
  • (v)
    square
Question 22
22.
Sum of the interior angles in a triangle is
  • (i)
    195°
  • (ii)
    210°
  • (iii)
    185°
  • (iv)
    180°
  • (v)
    190°
Question 23
23.
Sum of the interior angles in a quadrilateral is
  • (i)
    360°
  • (ii)
    390°
  • (iii)
    370°
  • (iv)
    375°
  • (v)
    365°
Question 24
24.
Sum of the interior angles in a pentagon is
  • (i)
    540°
  • (ii)
    550°
  • (iii)
    570°
  • (iv)
    555°
  • (v)
    545°
Question 25
25.
Sum of the interior angles in a hexagon is
  • (i)
    720°
  • (ii)
    730°
  • (iii)
    750°
  • (iv)
    735°
  • (v)
    725°
Question 26
26.
Sum of the interior angles in a heptagon is
  • (i)
    930°
  • (ii)
    900°
  • (iii)
    910°
  • (iv)
    905°
  • (v)
    915°
Question 27
27.
Sum of the interior angles in an octagon is
  • (i)
    1110°
  • (ii)
    1080°
  • (iii)
    1085°
  • (iv)
    1090°
  • (v)
    1095°
Question 28
28.
Sum of the interior angles in a nonagon is
  • (i)
    1270°
  • (ii)
    1290°
  • (iii)
    1265°
  • (iv)
    1275°
  • (v)
    1260°
Question 29
29.
Sum of the interior angles in a decagon is
  • (i)
    1470°
  • (ii)
    1445°
  • (iii)
    1455°
  • (iv)
    1450°
  • (v)
    1440°
Question 30
30.
How many diagonals does a triangle have?
  • (i)
    1
  • (ii)
    4
  • (iii)
    0
  • (iv)
    3
  • (v)
    2
Question 31
31.
How many diagonals does a quadrilateral have?
  • (i)
    0
  • (ii)
    3
  • (iii)
    4
  • (iv)
    1
  • (v)
    2
Question 32
32.
How many diagonals does a pentagon have?
  • (i)
    3
  • (ii)
    6
  • (iii)
    4
  • (iv)
    5
  • (v)
    7
Question 33
33.
How many diagonals does a hexagon have?
  • (i)
    8
  • (ii)
    10
  • (iii)
    9
  • (iv)
    7
  • (v)
    12
Question 34
34.
How many diagonals does a heptagon have?
  • (i)
    14
  • (ii)
    13
  • (iii)
    17
  • (iv)
    11
  • (v)
    15
Question 35
35.
How many diagonals does an octagon have?
  • (i)
    19
  • (ii)
    22
  • (iii)
    20
  • (iv)
    21
  • (v)
    18
Question 36
36.
How many diagonals does a nonagon have?
  • (i)
    26
  • (ii)
    27
  • (iii)
    24
  • (iv)
    29
  • (v)
    28
Question 37
37.
How many diagonals does a decagon have?
  • (i)
    34
  • (ii)
    35
  • (iii)
    36
  • (iv)
    37
  • (v)
    33
Question 38
38.
    • Find the number of sides in a regular polygon if each
    • interior
    • angle is
    • 156°
  • (i)
    16
  • (ii)
    13
  • (iii)
    15
  • (iv)
    14
  • (v)
    17
Question 39
39.
    • Find the number of sides in a regular polygon if each
    • exterior
    • angle is
    • 18°
  • (i)
    23
  • (ii)
    20
  • (iii)
    19
  • (iv)
    17
  • (v)
    21
Question 40
40.
The number of diagonals in a regular polygon with n sides is
  • (i)
    (
    n
    ) (
    n
    +
    2
    )

    2
  • (ii)
    (
    n
    ) (
    n
    −
    1
    )

    2
  • (iii)
    (
    n
    ) (
    n
    −
    2
    )

    2
  • (iv)
    (
    n
    ) (
    n
    +
    3
    )

    2
  • (v)
    (
    n
    ) (
    n
    −
    3
    )

    2
Question 41
41.
The value of each exterior angle in an n-sided regular polygon is
  • (i)
    [
    (2n - 4) x 90

    n
    ] °
  • (ii)
    (
    360

    n
    ) °
  • (iii)
    [
    (2n - 4) x 180

    n
    ] °
  • (iv)
    (
    n

    360
    ) °
Question 42
42.
The value of each interior angle in an n-sided regular polygon is
  • (i)
    (
    n

    360
    ) °
  • (ii)
    [
    (2n - 4) x 90

    n
    ] °
  • (iii)
    [
    (2n - 4) x 180

    n
    ] °
  • (iv)
    (
    360

    n
    ) °
Question 43
43.
The value of the exterior angle in a regular polygon when the interior angle is given
  • (i)
    180°+ (interior angle)
  • (ii)
    90°+ (interior angle)
  • (iii)
    180°- (interior angle)
  • (iv)
    360°- (interior angle)
Question 44
44.
The value of the interior angle in a regular polygon when the exterior angle is given
  • (i)
    90°+ (exterior angle)
  • (ii)
    360°- (exterior angle)
  • (iii)
    180°+ (exterior angle)
  • (iv)
    180°- (exterior angle)
    Assignment Key

  •  1) (v)
  •  2) (i)
  •  3) (ii)
  •  4) (ii)
  •  5) (v)
  •  6) (i)
  •  7) (iii)
  •  8) (ii)
  •  9) (iii)
  •  10) (iv)
  •  11) (iii)
  •  12) (ii)
  •  13) (v)
  •  14) (ii)
  •  15) (iv)
  •  16) (iii)
  •  17) (v)
  •  18) (ii)
  •  19) (iv)
  •  20) (iii)
  •  21) (v)
  •  22) (iv)
  •  23) (i)
  •  24) (i)
  •  25) (i)
  •  26) (ii)
  •  27) (ii)
  •  28) (v)
  •  29) (v)
  •  30) (iii)
  •  31) (v)
  •  32) (iv)
  •  33) (iii)
  •  34) (i)
  •  35) (iii)
  •  36) (ii)
  •  37) (ii)
  •  38) (iii)
  •  39) (ii)
  •  40) (v)
  •  41) (ii)
  •  42) (ii)
  •  43) (iii)
  •  44) (iv)
