EduSahara™ Worksheet
Name : Chapter Based Worksheet
Chapter : Area of Plane Figures
Grade : SSC Grade VIII
License : Non Commercial Use
Question 1
1.
In rhombus PQRS, if diagonals QS = 19.00 cm and PR = 17.75 cm, the area of the rhombus =
  • (i)
    153.62 sq.cm
  • (ii)
    182.62 sq.cm
  • (iii)
    168.62 sq.cm
  • (iv)
    160.62 sq.cm
Question 2
2.
If the length of the arc of a sector is 34.47 cm and the perimeter of the circle is 88.00 cm, the perimeter of the sector is
  • (i)
    65.47 cm
  • (ii)
    59.47 cm
  • (iii)
    67.47 cm
  • (iv)
    62.47 cm
  • (v)
    57.47 cm
Question 3
3.
If the side of a square is 10.00 cm, the perimeter of the square =
  • (i)
    45.00 cm
  • (ii)
    40.00 cm
  • (iii)
    35.00 cm
  • (iv)
    43.00 cm
  • (v)
    37.00 cm
Question 4
4.
In a right angled triangle △PQR, if the base QR = 18 cm and the corresponding height is 15 cm, then side RP =
  • (i)
    20.43 cm
  • (ii)
    18.43 cm
  • (iii)
    23.43 cm
  • (iv)
    28.43 cm
  • (v)
    26.43 cm
Question 5
5.
If the perimeter of a square is 56.00 cm, the side of the square =
  • (i)
    14.00 cm
  • (ii)
    9.00 cm
  • (iii)
    17.00 cm
  • (iv)
    11.00 cm
  • (v)
    19.00 cm
Question 6
6.
If the length and breadth of a rectangle are 17.00 cm and 15.00 cm respectively, the area of the rectangle =
  • (i)
    231.00 sq.cm
  • (ii)
    247.00 sq.cm
  • (iii)
    255.00 sq.cm
  • (iv)
    272.00 sq.cm
Question 7
7.
In the given figure, BC = 8 cm and AB = 14 cm. Find the area of the shaded region
  • (i)
    163.29 sq.cm
  • (ii)
    135.29 sq.cm
  • (iii)
    148.29 sq.cm
  • (iv)
    140.29 sq.cm
  • (v)
    172.29 sq.cm
Question 8
8.
In an isosceles right angled triangle △PQR, if corresponding height to the base QR is 14 cm, then side QR =
  • (i)
    14.00 cm
  • (ii)
    11.00 cm
  • (iii)
    9.00 cm
  • (iv)
    19.00 cm
  • (v)
    17.00 cm
Question 9
9.
If the length and perimeter of a rectangle are 18.00 cm and 58.00 cm respectively, the length of the diagonal =
  • (i)
    24.10 cm
  • (ii)
    16.10 cm
  • (iii)
    21.10 cm
  • (iv)
    26.10 cm
  • (v)
    18.10 cm
Question 10
10.
In an isosceles right angled triangle △PQR, if QR = 11 cm is one of the equal sides, then side RP =
  • (i)
    20.56 cm
  • (ii)
    12.56 cm
  • (iii)
    18.56 cm
  • (iv)
    15.56 cm
  • (v)
    10.56 cm
Question 11
11.
In an isosceles triangle △ABC, if BC = 11 cm, CA = AB and perimeter is 35 cm, then corresponding height of side BC =
  • (i)
    10.67 cm
  • (ii)
    13.67 cm
  • (iii)
    7.67 cm
  • (iv)
    15.67 cm
  • (v)
    5.67 cm
Question 12
12.
In an isosceles right angled triangle △PQR, if RP = 18.38 cm is the hypotenuse, then side PQ =
  • (i)
    8.00 cm
  • (ii)
    18.00 cm
  • (iii)
    16.00 cm
  • (iv)
    13.00 cm
  • (v)
    10.00 cm
Question 13
13.
In a right angled triangle △PQR, if the area is 71.5 sq.cm and corresponding height of side QR = 13 cm, then side QR =
  • (i)
    16.00 cm
  • (ii)
    14.00 cm
  • (iii)
    11.00 cm
  • (iv)
    8.00 cm
  • (v)
    6.00 cm
Question 14
14.
If the perimeter and diagonal of a rectangle are 34.00 cm and 12.04 cm respectively, the length of the rectangle =
  • (i)
    8.00 cm
  • (ii)
    9.00 cm
  • (iii)
    11.00 cm
  • (iv)
    7.00 cm
  • (v)
    10.00 cm
Question 15
15.
Find the area of shaded region in the adjoining figure, given that DE = 14 cm, EF = 28 cm, DG = 18 cm and ∠GDE = ∠DEF = 90°.
  • (i)
    323.00 sq.cm
  • (ii)
    321.00 sq.cm
  • (iii)
    324.00 sq.cm
  • (iv)
    320.00 sq.cm
  • (v)
    322.00 sq.cm
Question 16
16.
If the area of the inner circle of the ring is 254.57 sq.cm and area of outer circle is 314.29 sq.cm, the area of the ring is
  • (i)
    56.71 sq.cm
  • (ii)
    59.71 sq.cm
  • (iii)
    64.71 sq.cm
  • (iv)
    54.71 sq.cm
  • (v)
    62.71 sq.cm
Question 17
17.
If the perimeter of a square is 68.00 cm, the area of the square =
  • (i)
    295.00 sq.cm
  • (ii)
    307.00 sq.cm
  • (iii)
    266.00 sq.cm
  • (iv)
    289.00 sq.cm
  • (v)
    274.00 sq.cm
Question 18
18.
If the area of a sector of a circle is 89.79 sq.cm and the angle subtended at the center by the arc of the sector is 85.00°, the area of the circle is
  • (i)
    394.29 sq.cm
  • (ii)
    392.29 sq.cm
  • (iii)
    365.29 sq.cm
  • (iv)
    362.29 sq.cm
  • (v)
    380.29 sq.cm
Question 19
19.
If perimeter of an equilateral triangle 30 cm, the height of the equilateral triangle =
  • (i)
    6.66 cm
  • (ii)
    10.66 cm
  • (iii)
    7.66 cm
  • (iv)
    9.66 cm
  • (v)
    8.66 cm
Question 20
20.
If height of an equilateral triangle is 10.39 cm, the perimeter of the equilateral triangle =
  • (i)
    39.00 cm
  • (ii)
    36.00 cm
  • (iii)
    33.00 cm
  • (iv)
    31.00 cm
  • (v)
    41.00 cm
Question 21
21.
If the area of a sector of a circle is 130.95 sq.cm and the length of the arc of the sector is 26.19 cm, the angle subtended at the center by the arc of the sector is
  • (i)
    150.00°
  • (ii)
    168.00°
  • (iii)
    165.00°
  • (iv)
    134.00°
  • (v)
    146.00°
Question 22
22.
If the width of the ring is 4.00 cm and outer radius is 10.00 cm, the inner circle radius is
  • (i)
    8.00 cm
  • (ii)
    4.00 cm
  • (iii)
    5.00 cm
  • (iv)
    6.00 cm
  • (v)
    7.00 cm
Question 23
23.
If the length and breadth of a rectangle are 12.00 cm and 8.00 cm respectively, the length of the diagonal =
  • (i)
    17.42 cm
  • (ii)
    11.42 cm
  • (iii)
    9.42 cm
  • (iv)
    14.42 cm
  • (v)
    19.42 cm
Question 24
24.
In an isosceles triangle △ABC, if BC = 14 cm, AB = CA = 19 cm, then area of the triangle =
  • (i)
    123.64 sq.cm
  • (ii)
    147.64 sq.cm
  • (iii)
    107.64 sq.cm
  • (iv)
    135.64 sq.cm
  • (v)
    98.64 sq.cm
Question 25
25.
If the radius of a circle is 15.00 cm and the area of a sector is 139.46 sq.cm, the angle subtended at the center by the arc of the sector is
  • (i)
    71.00°
  • (ii)
    68.00°
  • (iii)
    66.00°
  • (iv)
    74.00°
  • (v)
    76.00°
    Assignment Key

  •  1) (iii)
  •  2) (iv)
  •  3) (ii)
  •  4) (iii)
  •  5) (i)
  •  6) (iii)
  •  7) (iii)
  •  8) (i)
  •  9) (iii)
  •  10) (iv)
  •  11) (i)
  •  12) (iv)
  •  13) (iii)
  •  14) (ii)
  •  15) (v)
  •  16) (ii)
  •  17) (iv)
  •  18) (v)
  •  19) (v)
  •  20) (ii)
  •  21) (i)
  •  22) (iv)
  •  23) (iv)
  •  24) (i)
  •  25) (i)
